Keysight N9030B Series Installation Note
Signal analyzers, option fbp, full bypass path
Hide thumbs
Also See for N9030B Series:
- Installation note (18 pages) ,
- User reference (3520 pages) ,
- Programmer's reference manual (2650 pages)
Related Manuals for Keysight N9030B Series
Summary of Contents for Keysight N9030B Series
- Page 1 Keysight Technologies N9030B Signal Analyzers Option FBP, Full Bypass Path Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 N9030B-B2X or B5X N9030B-MPB and N9030B-LNP Restrictions: Cannot be installed on instruments with Option 503 To Be Performed By: (X) Keysight Service Center ( ) Personnel Qualified by Keysight ( ) Customer Estimated Installation Time: 1.0 Hours Estimated Adjustment Time: 4.0 Hours Estimated Verification Time: 2.0 Hours...
- Page 4 — Personal computer with internet access and USB port — USB storage device with > 3 GB free memory — Keysight Calibration and Adjustment Software, N7814A (revision E.24.00 or later required) — Test equipment and computer supported by the Keysight Calibration and Adjustment Software Installation Note N9030-90122...
-
Page 5: Initial Instrument Functionality Check
If the instrument software is earlier than A.25.00, you must upgrade to version A.25.00 or later. Keysight recommends that you update to the latest instrument software version to ensure that you have the latest defect fixes. To check the latest instrument software version, visit the following website: http://www.keysight.com/find/xseries_software... - Page 6 Option FBP, Full Bypass Path 6. Refer to the data in step 3 above. Verify that both N9030B-MPB and N9030B-LNP are checked (currently installed). Verify that N9030B-B2X or N9030B-B5X is checked (currently installed). If these options are not installed, do not proceed with the installation of this kit. Installation Note N9030-90122...
-
Page 7: License Installation Procedure Over Usb
USB Storage Device Configuration Menu 7. The signal analyzer will automatically consume the License File (this may take a few minutes). When the License File is consumed the Keysight License Manager will display a “Successful License Installation” message as shown in... - Page 8 Option FBP, Full Bypass Path Alternate Installation Procedure The License File can be manually installed over USB or LAN by placing the license file in the following folder on the signal analyzer C:\Program Files\Agilent\licensing Verify the License Installation and Hardware 1.
- Page 9 To verify the current version, press System, Show System and look for the "Instrument S/W Revision". The latest revision of the X-Series Signal Analyzers software may be downloaded from: http://www.keysight.com/find/xseries_software Verify Option FBP Functionality 1. Press MODE/MEAS, and select Spectrum Analyzer, Swept SA.
-
Page 10: Adjustments Required
IF Phase Linearity Utility and print the output file For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL, or if in the United States, call the following telephone number: http://www.keysight.com/find/assist... - Page 11 This information is subject to change without notice. © Keysight Technologies 2019 Edition 1, November 2019 N9030-90122 www.keysight.com...
