Select the [SOURce:]VOLTage:MODE ARB parameter to enable the instrument to generate arbit-
l
rary voltage waveforms when the transient system is initiated and triggered.
Select the [SOURce:]CURRent:MODE ARB parameter to enable the instrument to generate arbit-
l
rary current waveforms when the transient system is initiated and triggered.
[SOURce:]ARB:FUNCtion:TYPE <type>, (@<chanlist>)
[SOURce:]ARB:FUNCtion:TYPE? (@<chanlist>)
This command replaces the previous [SOURce:]ARB:FUNCtion command and should be
used in new applications. [SOURce:ARB:FUNCtion is still available for backward
compatibility
Selects either a voltage or current ARB. Only one type of ARB may be output at a time.
Parameter
CURRent | VOLTage, *RST VOLTage
Specify an Arb type on channel 1: ARB:FUNC:TYPE CURR, (@1)
[SOURce:]ARB:TERMinate:LAST <Bool>, (@<chanlist>)
[SOURce:]ARB:TERMinate:LAST? (@<chanlist>)
Determines the output value when the ARB terminates. The state is either ON (1) or OFF (0).
When ON The output voltage or current remains at the last ARB sequence value. The last voltage or cur-
rent ARB value becomes the IMMediate value when the ARB completes.
When OFF The output returns to the settings that were in effect before the ARB started. This also applies
when the ARB is aborted,
0|OFF|1|ON, *RST Off
Sets the ARB to terminate with the voltage or current set at the last ARB value:
ARB:TERM:LAST ON,(@1)
The query returns 0 if the output returns to the settings that were in effect before the ARB started,
l
and 1 if the output voltage or current remains at the last ARB value.
Keysight N6705C Operating and Service Guide
Parameter
7 SCPI Programming Reference
Typical Return
<type>
Typical Return
0 or 1
