7 SCPI Programming Reference
TRIGger:ACQuire:CURRent:SLOPe POSitive|NEGative, (@<chanlist>)
TRIGger:ACQuire:CURRent:SLOPe? (@<chanlist>)
TRIGger:ACQuire:VOLTage:SLOPe POSitive|NEGative, (@<chanlist>)
TRIGger:ACQuire:VOLTage:SLOPe? (@<chanlist>)
Sets the slope of the signal. Applies when the measurement trigger source is set to a level.
POSitive specifies a rising slope of the output signal.
NEGative specifies a falling slope of the output signal.
Parameter
POSitive|NEGative, *RST POSitive
Sets the current slope to falling edge: TRIG:ACQ:CURR:SLOP NEG, (@1)
Sets the voltage slope to falling edge: TRIG:ACQ:VOLT:SLOP NEG, (@1)
TRIGger:ACQuire:TOUTput[:ENABle] 0|OFF|1|ON, (@<chanlist>)
TRIGger:ACQuire:TOUTput[:ENABle]? (@<chanlist>)
Enables measurement triggers to be sent to a digital port pin. The digital port pin must be configured
as trigger output before it can be used as a trigger source (see
Parameter
0|OFF|1|ON, *RST OFF
Enable sending measurement triggers to digital pins: TRIG:ACQ:TOUT ON, (@1)
TRIGger:ACQuire:SOURce <source>, (@<chanlist>)
TRIGger:ACQuire:SOURce? (@<chanlist>)
TRIGger:ARB:SOURce <source>
TRIGger:ARB:SOURce? (@<chanlist>)
TRIGger:DLOG:SOURce <source>
TRIGger:DLOG:SOURce? (@<chanlist>)
TRIGger:ELOG:SOURce <source>, (@<chanlist>)
TRIGger:ELOG:SOURce? (@<chanlist>)
TRIGger:HISTogram:SOURce <source>, (@<chanlist>)
TRIGger:HISTogram:SOURce? (@<chanlist>)
TRIGger:TRANsient:SOURce <source>, (@<chanlist>)
TRIGger:TRANsient:SOURce? (@<chanlist>)
TRIGger:ACQuire:SOURce - selects the trigger source for the acquisition system.
TRIGger:ARB:SOURce - selects the trigger source for the arbitrary waveform generator.
TRIGger:DLOG:SOURce - selects the trigger source for internal data logging.
TRIGger:ELOG:SOURce - selects the trigger source for external data logging.
TRIGger:HISTogram:SOURce - selects the trigger source for the current histogram.
TRIGger:TRANsient:SOURce - selects the trigger source for the transient system.
340
Typical Return
POS or NEG
Trigger
Typical Return
0 or 1
Output).
