8 Verification and Calibration
Test Record Form - Keysight N6764A and N6766A
N6764A and N6766A
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
Low Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 100 μs:
Voltage @ 100 μs with Option 760/761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
Low Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
Voltage Readback Low:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
Current Readback Low:
CC Load Effect, Source Effect:
424
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both +13 mV
Both Vout − 25 mV
Both 59.970 V
Both Vout − 43 mV
Both Vout − 6.8 mV
Both – 2 mV
Both – 1.2 mV
Both N/A
Both N/A
Both – 90 mV
Both – 350 mV
Constant Current Tests
Both + 16 mA
Both Iout − 5 mA
N6764A 19.981 A
N6766A 16.9833 A
N6764A Iout − 25 mA
N6766A Iout − 22 mA
Bpth Iout − 1 mA
– 5 mA
– 2 mA
N6764A Setting
25 mV, 5 A
60 V, 5 A
6 V 5 A
60 V, 5 A
15 V, from 10 A to 20 A
20 mA, 15 V
20 A, 15 V
0.5 A, 15 V
20 A, 15 V
Date__________
Results
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
N6766A Setting
25 mV, 8.33 A
60 V, 8.33 A
6 V, 8.33 A
60 V, 8.33 A
29 V, from 8.5 A to 17 A
20 mA, 29 V
17 A, 29 V
0.5 A, 29 V
17 A, 29 V
Keysight N6705C Operating and Service Guide
Max. Specs
+ 37 mV
Vout + 25 mV
60.030 V
Vout + 43 mV
Vout + 6.8 mV
+ 2 mV
+ 1.2 mV
+ 6 mV
+ 1 mV
+ 90 mV
+ 350 mV
+ 24 mA
Iout + 5 mA
20.019 A
17.0167 A
Iout + 25 mA
Iout + 22 mA
Iout + 1 mA
+ 5 mA
+ 2 mA
