8 Verification and Calibration
Test Record Form - Keysight N6761A and N6762A
N6761A and N6762A
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
Low Range Voltage Prog. & Readback
Low Voltage Vout:
Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 150 μs:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
Low Range Current Prog. & Readback
Low Current (full-scale) Iout:
Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
Voltage Programming & Readback Low Voltage:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
Current Programming & Readback Low Current:
Current Readback 100 µA Current:
Current Readback 200 µA Current:
CC Load Effect, Source Effect:
422
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both + 9 mV
Both Vout − 6 mV
Both 49.986 V
Both Vout − 14 mV
Both 5.4976 V
Both Vout – 2.4 mV
Both – 0.5 mV
Both – 0.5 mV
Both N/A
Both N/A
Both – 75 mV
Constant Current Tests
Both − 0.8 mA
Both Iout − 160 µA
N6761A 1.4992 A
N6762A 2.9986 A
N6761A Iout − 0.76 mA
N6762A Iout − 1.36 mA
Both 0.099930 A
Both Iout − 45 µA
Both – 65 µA
Both – 30 µA
N6761A Setting
15 mV, 1 A
50 V, 1 A
5.5 V 1 A
50 V, 1 A
33 V, from 0.9 A to 1.5 A
1 mA, 33 V
1.5 A, 33 V
0.1 A, 33 V
1 mA, 1.9 V
1 mA, 3.9 V
1.5 A, 33 V
Date__________
Results
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
_______
N6762A Setting
15 mV, 2 A
50 V, 2 A
5,5 V, 2 A
50 V, 2 A
33 V, from 1.5 A to 3 A
1 mA, 33 V
3 A, 33 V
0.1 A, 33 V
1 mA, 1.9 V
1 mA, 3.9 V
3 A, 33 V
Keysight N6705C Operating and Service Guide
Max. Specs
+ 21 mV
Vout + 6 mV
50.014 V
Vout + 14 mV
5.5024 V
Vout + 2.4 mV
+ 0.5 mV
+ 0.5 mV
+ 4.5 mV
+ 0.35 mV
+ 75 mV
+ 1.2 mA
Iout + 160 µA
1.5008 A
3.0014 A
Iout + 0.76 mA
Iout + 1.36 mA
0.100070 A
Iout + 45 µA
+ 65 µA
+ 30 µA
