The front panel screen

NOTE
The screen on the front panel consists of three lines.

Figure 10: The front panel screen

The information displayed on the top line depends on the task you are performing. It can
display:
•
•
The next line is called the active line. You can use this line to indicate the list or entry
you want to select, to enter text, and to change the value in a setting.
The third line is used when a list is displayed to show either the next item in the list
(Figure
value is displayed, it is indented under the name of the entry to which it applies. In
Figure 11
The name of each soft function key represents the action that will take place when the
corresponding F1, F2 or F3 key on the front panel of the transceiver is pressed.

Figure 11: The front panel screen displaying a value

The front panel screen also displays information screens such as the channel screen in
the Channel List, and the time screen in the Control List.
Manpack Transceiver 2110 series Reference Manual
In the following example, you must log in as administrator to see the
Main Menu (see
page 104, The Main
the name of the list, entry or setting you are in
the Find prompt when you press
10), or the value in the first or only setting for the entry
the value indicates that the Screen Brightness is set to Bright.
page 128, Logging in to admin level from user level
Menu).
top line
active line
next item
soft function keys
top line
active line
value
Operating the transceiver
and
(Figure 11). When a
