HF SSB Transceiver
9323, 9360, 9390 and 9780
Technical Service Manual
No part of this handbook may be reproduced, transcribed, translated into any
language or transmitted in any form whatsoever without the prior written consent
of Codan Pty Ltd
© 1994 Codan Pty Ltd.
Codan part number 15-02051 Issue 4, August 1997
