Figure 39: An incoming call screen for a NET call (MIL-STD-188-141B ALE
NET call
ALE selective
message
If you receive one or more calls while the transceiver is unattended, the incoming call
screen displays the details of the most recent call. The call count number at the bottom
right of the screen indicates the number of calls received since the first call (see
Figure
To remove the incoming call screen:
1
Error reporting in a received AMD message
NOTE
If you receive a call containing a message in which an error has been detected, the
corrupted part of the message is replaced with reverse-highlighted bullets.

The Calls In Log

When you receive a call, an entry is created in the Calls In Log. The entry lists:
•
•
•
•
•
•
•
NOTE
Manpack Transceiver 2110 series Reference Manual
option, 2110 only)
icon
37).
Press .
AMD messaging is available if you have the MIL-STD-188-141B ALE
option installed (2110 only).
the type of call received and the address of the caller
the message, GPS position or status information received if the call was a Message,
Get Position, or Get Status call
the time at which the call was received
the self address to which the call was sent
the network in which the call was received
the channel/mode on which the call was received
the phone link that was used, if the call was a Phone call
Entries are not created for Channel Test, Get Position, and Get Status
calls.
Making and receiving calls
address of caller and
name of NET
call count
number
221
