Lqa Command - Codan 2110 series Reference Manual

Operating the transceiver from a computer

lqa command

If you have the MIL-STD-188-141B ALE option installed, you can use the
lqa command to:
•
•
The LQA information comprises local and remote data. The local LQA information
indicates the quality of the signal that the local station has received from the remote
station. The remote LQA information indicates the quality of the signal that the remote
station has received from the local station.
NOTE
Syntax
lqa
lqa output
lqa output on
lqa output off
where:
lqa displays the LQA information from the current or last-established ALE link since
startup of the transceiver.
output displays the current status of the asynchronous output.
on enables asynchronous output of LQA information, that is, displaying LQA output as
it is sent or received. Information provided includes channel name, current station, local
BER/SINAD, remote BER/SINAD, and LQA score.
off disables asynchronous output of LQA information (default startup state).
428
display the LQA information from the current or last-established ALE link since
startup of the transceiver
enable or disable the asynchronous output of LQA information on LQA exchanges
or soundings
In order to receive remote LQA information, the remote station must have
ALE LQA Exchange switched on (see
the Control List and page 228, Entries in the Control
Manpack Transceiver 2110 series Reference Manual
page 112, Changing a setting in
List).
