Figure 57: Front View Of The External Gps Antenna Connector (2110 Only); Table 45: Pinouts Of The External Gps Antenna Connector (2110 Only) - Codan 2110 series Reference Manual

Connectors
Pinouts of the external GPS antenna connector (2110 only)
The external GPS antenna connector provides an interface for GPS signals. It
automatically detects signals and sends these to the internal GPS receiver for processing.

Figure 57: Front view of the external GPS antenna connector (2110 only)

Table 45:
Connection Function
Centre pin
Sleeve
For specifications of this connector see
356
Pinouts of the external GPS antenna connector (2110 only)
Active GPS antenna
GPS antenna ground
Table 55 on page 383.
