GPS Screen entry

NOTE
NOTE
The GPS antenna and receiver is a hardware option that is fitted internally. If the
2110 series Manpack Transceiver is mounted in a vehicle, an external GPS antenna may
be connected to the optional GPS connector to provide GPS signals to the transceiver.
Alternatively, a GPS receiver may be connected to the 19-way connector to provide GPS
information to the transceiver. The option must be enabled in the firmware by an option
code.
The GPS Screen entry in the Control List enables you to display your current GPS
position. Press GPS to access the GPS screen.
You can configure the GPS receiver to report in metric or imperial units using the
Cfg Units entry in the Control List. You can also use a special configuration command in
the Message 10 entry that provides GPS readings in degrees, minutes and seconds (see
page 482, Enabling GPS format

Figure 47: The GPS Screen entry in the Control List

new reading indicator
NOTE
Table 33
information is provided by the GPS receiver. In normal situations, you only see
automatic readings.
The new reading indicator is a number that increments each time a new reading is
received. Each increment confirms that your GPS receiver is functioning correctly. The
indicator cycles from 1 to 9.
Table 33:
On GPS screen
Manpack Transceiver 2110 series Reference Manual
The GPS Screen entry is only displayed if Option GPS Enable is installed
in the transceiver.
The GPS receiver should be pointed toward the sky and should not be
shadowed by overhead obstructions.
type of reading
GPS receivers sometimes take time to acquire an altitude reading that is
accurate. You may find that the altitude reading fluctuates for the first few
readings.
explains the abbreviations for each type of reading you may receive. This
Types of readings on the GPS screen
Abbreviation
Aut
Bad
options).
In message text
A
N
altitude
latitude
longitude
Description
Automatic reading
Bad reading
The Control List
259
