Figure 5: Typical Front Panel Of A Battery Charger; Table 5: Led Indications - Codan 2110 series Reference Manual

Figure 5:
3121 AC Battery Charger
INPUT
Table 5:
Charger
type
3121
3122
3522
3123
3523
Manpack Transceiver 2110 series Reference Manual
Typical front panel of a battery charger
OUTPUT
LED indications
LED Status
Green, solid
Off
OUTPUT Orange, solid
Off
Green, solid
Off
OUTPUT Yellow, solid
Yellow, slow
flash
Yellow/red,
alternating flash
Red, double
flash then long
pause
Red, rapid flash The battery pack is unserviceable and cannot
Preparing the transceiver for use
Meaning
The charger has an appropriate power supply
connected.
The charger does not have an appropriate
power supply connected.
The charger is charging the battery pack.
The charger has finished charging the battery
pack.
The charger has an appropriate power supply
connected.
The charger does not have an appropriate
power supply connected, or is not functioning
correctly.
The charger is charging the battery pack.
The charger has finished charging the battery
pack.
The battery pack has an overtemperature
condition.
The battery pack has a faulty fuse.
be charged.
29
