Codan 2110 series Reference Manual page 255

Table 31:
Name of entry
RS232 Mode
(2110 only)
RS232 Speed
RS232 Startup
(2110 only)
Scan
Scan Allow
Screen Auto-Dim
Screen Brightness
Screen Contrast
Screen Scroll Rate
Screen Scroll Step
Secure Index
Secure Key
Manpack Transceiver 2110 series Reference Manual
Entries in the Control List (cont.)
Use this entry to...
Set the mode in which the RS232 19-way serial port operates.
If the port is:
• not in use, select None
• receiving GPS information from an external GPS receiver,
select GPS
• controlling and monitoring the transceiver, select CICS
• connected to a 9001/3012 modem, select Fax/Data
• connected to a radio/telephone interconnect unit, select
3033/RTU–292
• connected to a single-tone low-rate FSK Pactor modem, select
Pactor 1
• connected to a multi-tone/PSK HAL or Clover modem, select
HAL/Clover
• connected to a multi-tone modem, select Modem Slow AGC
• connected to a non-Codan modem located in an area that is
prone to frequent lightning strikes, select Modem Fast AGC
(this may improve the performance)
• connected to a VP-116 Voice Privacy Unit, select VP-116
Set the data rate of the RS232 19-way serial port.
Set the serial commands you want to have performed by the
19-way port following power on, for example, setting the self
address that is used by CICS during transmissions, echo off etc.
For more information see
Switch scanning on or off.
Enable or disable scanning.
Set the time the transceiver waits after a key is pressed before
switching off the backlighting on the front panel screen. The
backlighting is automatically switched on again when a key is
pressed.
Set the brightness of the screen.
Set the contrast of the screen.
Set the speed with which characters on the screen scroll when the
line length exceeds the screen width.
Set the number of characters on the screen that scroll as a block
when the line length exceeds the screen width.
Select the Corporate secure index.
Set the CES secure key or AES secure key for a particular secure
index.
page 265, RS232 Startup
The Control List
Default
None
9600
entry.
Yes
1 minute
0.8 seconds
2
239
