Removing the access panel

Procedure
1. Use the T-15 Torx screwdriver attached to the rear of the server to loosen the security screw on the
hood latch.
2. Lift the hood latch handle, and then remove the access panel.
To replace the component, reverse the removal procedure.
Removing the PCI riser cage
CAUTION:
For proper cooling, do not operate the server without the access panel, baffles, expansion slot
covers, or blanks installed. If the server supports hot-pluggable components, minimize the amount
of time the access panel is open.
Procedure
1. Disconnect any cables connected to optional I/O cards before removing cage.
2. Remove the PCI riser cage.
