To replace the component, see Installing a hot-swappable power supply on page 58.

Removing and replacing the access panel

To remove the access panel see Removing the access panel.
To replace the component, reverse the removal procedure.
Removing and replacing the optical drive filler
To remove the component:
CAUTION:
To prevent improper cooling and thermal damage, do not operate the server unless all bays are
populated with either a component or a blank.
Procedure
1. Power off the server (Powering off the server).
2. Extend or remove the server from the rack.
3. Remove the access panel. See Removing the access panel.
4. Remove the fans 2 and 3. See Removing and replacing a hot-swap fan on page 150.
5. Push out the drive filler.
NOTE:
You might have to use a nonconductive tool with a length of at least 20 cm and a thickness of
about 1 mm to push out the drive filler. Hewlett Packard Enterprise recommends using a ruler or
similar tool.
To replace the component, reverse the removal procedure.
Removing and replacing the optical drive
CAUTION:
To prevent improper cooling and thermal damage, do not operate the server unless all bays are
populated with either a component or a blank.
Procedure
1. Power off the server (Powering off the server).
2. Extend or remove the server from the rack. See Removing the server from the rack.
3. Remove the access panel. See Removing the access panel.
4. Remove the fans 2 and 3. See Removing and replacing a hot-swap fan.
5. Disconnect the drive cable.
