WFM5200 Waveform Monitor User Manual
The Error Log is also divided into the following four columns:
Source: Shows the inputs on which the errors have occurred.
Error Status: Shows the current state of the entry: White items are
informational and identify a change in instrument state; Green items are
errors that have cleared; Red items are triggered errors.
Timecode: Shows the time, according to VITC or LTC in the signal, that the
error occurred. In the case of ongoing errors, this shows the time the error
first occurred.
Time: Shows the time, according to the internal clock, that the error occurred.
Error Log pop-up menu.
Mute Alarms: Mutes alarms for all Status display types.
Logging Active: Turns alarm error logging On or Off.
Logging Reset: Press the SEL button to clear the log.
Input/Channel: Allows you to select to filter errors in the error log so that
you can view them by channel or input. When the instrument is in SIM
mode, you can select to view errors from only Channel 1 (the left channel) or
Channel 2 (the right channel).
Save to USB (ALL): Saves the entire unfiltered error log to a USB memory
device.
Save to USB (Sel.): Saves only the errors in the error log for the selected
channel or input to a USB memory device.
Display Information
59
