ARIB Displays
118
DC - Data Count word of the acquired packet. The number of User Data
words is displayed in decimal. The actual value (with parity bits added) is
displayed in parenthesis, in hexadecimal.
Field - The field of the video from which the packet was acquired. Displays 1
for progressive formats.
Line - The line of the video (within the field) from which the packet was
acquired.
Stream - For HD (SMPTE 292M), indicates whether the ancillary packet was
acquired from the Y or C data streams. Displays N/A for SD.
Status - Indicates whether packet(s) of the desired type are present in the
video; also indicates Checksum or CRC errors.
Checksum - Indicates the checksum word that was recovered from the
acquired packet.
Should be - Indicates the checksum work computed by the instrument, based
on the packet data.
Format - Indicates the name of the ancillary data type or standard.
User Data Words - Contains the payload of the ancillary packet, displayed in
hexadecimal. Displays all 10 bits.
