Functions
Network Software
Installation
94
10. Select Continue from the upgrade window and press SEL to start the software
upgrade. (Select Cancel if you do not want to continue with the upgrade.)
WARNING.
To prevent upgrade failure, do not remove the USB flash drive or
power off the instrument until the upgrade is complete. The instrument displays
messages indicating the upgrade status. The upgrade may take up to 12 minutes.
11. When the process is complete, a message displays to cycle the power to the
instrument.
12. After the instrument finishes restarting, use the Configuration menu to verify
the correct software version installed.
13. Press the MAIN button and navigate to USB Unmount and press the SEL
button. This electrically unmounts the flash drive so that it can be safely
removed from the instrument.
Use the following steps to upgrade the instrument software using a network
connection:
1. Connect the instrument and PC to your local Ethernet network.
2. Power on the instrument.
3. Assign the instrument an IP address:
NOTE.
The data-transfer utility requires that the instrument be assigned a valid
IP address. To allow network access to the instrument, the instrument must be
assigned a valid IP address for your network. Network addresses can be assigned
either manually or automatically using DHCP. If your network does not use
DHCP, you will have to manually enter the address for the instrument. To get a
valid IP address, contact your local LAN administrator.
Alternatively, if you connect the PC directly to the instrument using an Ethernet
cable, you can assign the instrument any IP address that is compatible with the
IP address of the PC.
a. Press the CONFIG button on the front panel.
b. Navigate to Network Settings > IP Config Mode.
c. Select either Manual or DHCP as directed by your LAN administrator.
Select Manual if you are using an Ethernet cable to connect the PC
directly to the instrument.
d. If you selected Manual mode, enter the IP address, subnet mask, and
gateway address as directed by your LAN administrator. You need to
