To Select a Display
24
This instrument can support the following displays:
NOTE.
Some displays require a specific option to be installed. For example,
the Audio display is not accessible unless you have Option AUD. (See page 3,
Options.)
Waveform: YPbPr, YRGB, RGB, SDI → Composite or XYZ
Vector: Normal, SDI → Composite, Lightning, Luma Qualified Vector (On
or Off)
Gamut: Arrowhead, Spearhead, Diamond, Split Diamond, Quad Diamond
Measure: Timing, Datalist, Bowtie, ANC Data
Status: Error Log, Alarm Status, Video Session, Audio Session, Dolby Status,
Audio Loudness, Audio Control, Channel Status, Auxiliary Data Status
Audio: Phase, Surround, Loudness
Picture: Picture frame (on/off) and various closed caption and safe area
graticules
Push a front panel button corresponding to the display that you want to view and
one of the following selected displays will appear:
WFM: display of video waveform
VECTOR: display of vector and lightning plots of color signals
PICT: display of the picture generated by the video signal
AUDIO: display of levels (meters), phase (plot), and surround sound for
monitoring audio signals
GAMUT: display of one of four views for checking the gamut of an SDI
signal
STATUS: display of extensive views of signal status
MEAS: display of various measurements, including timing, audio video
delay, ANC data, and Data List
OTHER: display of the Longitudinal Time Code (LTC), External Reference
Waveform display, and Diagnostic Monitor
