Audio Monitoring

Configuring Audio Inputs
To Set Up an Audio Input

Selecting Audio Inputs

WFM5200 Waveform Monitor User Manual
Your instrument can monitor embedded audio signals if it has Option AUD
installed. It can measure levels, monitor phase, display phase correlation, and
monitor surround-sound audio. You can specify meter ballistics and scales, set
test and peak program indicator levels, and specify how phase is displayed.
NOTE.
The audio monitoring features described in this chapter requires that
Option AUD be installed. For a list of the options currently installed on your
instrument, press the CONFIG button. In the configuration menu, select Utilities.
The View Options entry lists the installed options.
Audio inputs come set to factory defaults. As a result, you may need to configure
them before performing the audio monitoring procedures in this section. The
first procedure helps you configure the inputs. After you have completed that
procedure, check that the alarms are configured as you want them. Your setup
here determines, in part, which audio-signal characteristics are displayed.
1. Press the CONFIG button to display the configuration menu.
2. Select Audio Inputs/Outputs and select the input to be configured.
3. Select from Srnd (Surround) for a 5.1 or 5.1+2 type display, or Pairs for a
stereo with SAP and discrete channels type installation.
4. Select Bar to Input Map and select which input pair should be displayed
in each bar pair.
5. Select which inputs are allowed to generate alarms.
6. Select the box to return to the Configuration menu.
7. Repeat these steps for any other Audio inputs.
You select the audio input to be monitored from the front-panel AUDIO button
pop-up menu. Note that the Audio display can appear in only one tile at a time.
1. Select a tile.
2. Press and hold the Audio button to open the Audio display in a tile and pop
up the Audio menu.
Audio Monitoring
