ARIB Displays

WFM5200 Waveform Monitor User Manual
Your instrument supports conformance to ARIB data standards contained in the
signal source. You will need to enable the ARIB displays from the Configuration
menu in the Aux Data Settings submenu. ARIB information is contained in the
following status screen displays:
ARIB Status
ARIB STD-B.39 Display
ARIB STD-B.37 Display
ARIB STD-B.35 Display
ARIB TR-B.23 (1) Display
ARIB TR-B.23 (2) Display
ARIB TR-B.22 Display
The following DID and SDID values are defined for common types of
ARIB-compliant data.
DID and SDID values for common ARIB data types
Ancillary data type
ARIB TR-B.22, Sub Information of transmitting materials
ARIB TR-B.23, Line 20 User Data - 1
ARIB TR-B.23, Line 20 User Data - 2
ARIB STD-B.35 Trigger Signal for Data Broadcasting
ARIB STD-B.37 Closed Captioning
Analog signal
SD signal
HD signal
ARIB STD-B.39 Inter Stationary Control Data
ARIB specification
ITU specification
ARIB Displays
DID SDID
value value
0x5F 0xE0
0x5F 0xFC
0x5F 0xFB
0x5F 0xFD
0x5F 0xDD
0x5F 0xDE
0x5F 0xDF
0x5F 0xFE
0x43 0x01
