Display Information
Picture Display Pop-Up
Menu
84
When monitoring to ensure that branding or other elements do not overlay
essential text or video action, use the PICT pop-up menu to select a Safe Action
and Safe Title graticule. The Safe Action Area is the maximum image area within
which all significant action should be contained, and the Safe Title Area is the
maximum image area within which all significant titles should be contained. You
can select standard or custom safe area graticules.
Picture Frame: Select to turn the picture frame On or Off.
CC/Teletext Format: Select from Off, Auto, CEA608, CEA708, and WST.
CEA608 CC Services: Select from CC Channel 1 through 4 and Txt Channel
1 through 4.
CEA708 CC Services: Select from Service 1 through 6.
TtxtB Page: Select the teletext B page.
Safe Area Action 1: Select from Off, Auto, 4x3, 14x9, 16x9, Custom_1,
and Custom_2.
Safe Area Title 1: Select from Off, Auto, 4x3, 14x9, 16x9, Custom_1, and
Custom_2.
Safe Area Action 2: Select from Off, Auto, 4x3, 14x9, 16x9, Custom_1,
and Custom_2.
Safe Area Title 2: Select from Off, Auto, 4x3, 14x9, 16x9, Custom_1, and
Custom_2.
Black/Frozen Grat: Select from Off, Black, and Frozen.
AFD Graticules: Select from ON and Off.
Picture Center Grat: Select from ON and Off.
