Software Upgrades - Tektronix WFM5200 User Manual

Functions

Software Upgrades

Obtain the Latest Software
92
8. In the same submenu, navigate to the Preset Group that matches the source
Preset Group and press the SEL button.
9. Press the left arrow key and then the down arrow key and highlight Copy.
10. Press the SEL button. You should see a pop-up notice that says Export
Complete.
11. If you do not want to export any other presets at this time, press the Preset
button to dismiss the menu.
12. Remove the USB memory device from the USB drive.
After you have verified that your instrument must have the software upgraded,
use the following procedures to upgrade the software.
After obtaining the latest software package, you can upgrade the instrument
either using the USB Software Installation procedure or the Network Software
Installation procedure.
Download the latest version of software available for your instrument.
1. Use the Web browser on your PC to navigate to the following Tektronix Web
site:
http://www.tektronix.com/downloads
2. On the Downloads Web page, search by model number (for example,
WFM5200) and filter by software and software type to locate the latest
software-upgrade package for the instrument.
3. Download the latest version to your PC.
4. After the software package is downloaded, click the self-extracting archive to
extract the following files into a directory of your choice. You should have
two file: transfer.exe and firmware.pkg. There may also be a readme.txt file.
WFM5200 Waveform Monitor User Manual
