Pop-Up Menus
To Set Display Parameters
WFM5200 Waveform Monitor User Manual
All pop-up menus are displayed by pressing and holding the specified display
button for three seconds. To hide a pop-up menu, press the specified button again.
Pop-up menus appear in the active tile and, in general, control only settings
specific that tile. A pop-up menu will not appear if it is not appropriate for the
current instrument setting (for example, trying to display the Gamut menu when
viewing a composite input signal).
Use the pop-up menus to set up the measurements that you display.
1. Select a tile by pressing the Display Select button.
2. Press and hold a display button and the display and the pop-up menu for
that display appears.
NOTE.
The selections in a pop-up menu can change depending on settings.
3. Use the right and left keys to move between menu panels. The instrument
surrounds the panel selected with a blue border.
4. Use the up and down arrow keys to select parameters in a menu. (See
Figure 10.)

Figure 10: Navigate menus using the arrow keys and select button

5. Navigate through the menu and make your selections.
Display Information
