Connecting Power

AC Adapter
Battery
Power-On
Power-Off
WFM5200 Waveform Monitor User Manual
The instrument operates from an external AC adapter with a line frequency of 50
or 60 Hz, over the range of 100-240 Volts, without the need for configuration,
except the power cord. The typical power draw is 27 Watts. Refer to the
WFM5200 Specifications and Performance Verification Technical Reference
on the Product Documentation CD for additional information on power and
environmental requirements.
This instrument can be powered by a 12 V DC input or by a 14.4 V standard
camera battery. If you are using a battery with this instrument, read the following
battery safety notices. This instrument was designed to be used with an Anton
Bauer battery. It can also be used with a Sony or IDX V-mount style battery.
CAUTION.
Before using the Anton Bauer Power Tap feature, refer to the product
information included with the battery. If that information is not available, contact
the battery manufacturer for information.
WARNING.
Fire can cause personal injury and/or property damage. To prevent
risk of fire, when using a 12 V DC source other than the provided AC adapter,
make sure that it has a suitable current limiting device (such as a fuse).
WARNING.
Risk of personal injury and/or property damage from falling
instrument. Batteries from various manufacturers may vary in shape and weight.
When a battery is installed, it is possible that it will make the unit too heavy in the
back, causing the instrument to tip backward.
1. Connect the supplied power cord to the rear-panel power connector. If you are
using a battery, connect the battery as explained in the installation instructions
that come with the battery.
2. Press the power button on the instrument front-panel and the instrument will
turn on.
NOTE.
The Standby button on the front-panel does not disconnect mains power.
Only the power cord at the rear of the product can disconnect mains power. Make
sure that the power cord is accessible when the product is operating.
1. Press the power button on the instrument front-panel to turn the instrument off.
2. To remove power completely, disconnect the power cord from the rear-panel
of the instrument.
