Importing Presets from a
USB Device
Exporting Presets to a USB
Device
WFM5200 Waveform Monitor User Manual
You can also save presets to the USB drive so that you can load them onto
multiple WFM5200 instruments in your system. To import presets to a USB
memory device:
1. Insert a USB memory device into the USB drive located in the front of the
instrument. To check that the drive mounted properly, press the MAIN button
and then press the SEL button.
2. Press and hold the Preset button to view the Preset menu.
3. Press the down arrow key to select Import Presets.
4. Press the right arrow key to access the submenu and then press the up/down
arrow keys to navigate to Select Source.
5. Press the right arrow key to access the submenu, highlight the USB folder
from which you want to import, and then press the SEL button.
6. Navigate to the Select Dest menu option and use the arrow keys to access
the submenu.
7. Navigate to the preset group that matches the source preset group and press
the SEL button.
8. Press the left arrow key and then the down arrow key and highlight Copy.
9. Press the SEL button. You should see a pop-up notice that says Import
Complete.
10. If you do not want to import any other presets at this time, press the Preset
button to dismiss the menu.
11. Remove the USB memory device from the USB drive.
To export presets to a USB memory device:
1. Insert a USB memory device into the USB drive located in the front of the
instrument. To check that the drive mounted properly, press the MAIN button
and then press the SEL button.
2. Press and hold the Preset button to view the preset menu.
3. Press the down arrow key to select Export Presets.
4. Press the right arrow key to access the submenu and then press the up/down
arrow keys to navigate to Select Source.
5. Press the right arrow key to access the submenu, highlight the Preset Group
you what to export to the USB memory device, and then press the SEL button.
6. Navigate to the Select Dest menu option and use the arrow keys to access
the submenu.
7. Select a USB folder if one exists or create a folder by following the
instructions for the Create USB Folder menu selection.
Functions
91
