SyncVu™

How to Change Settings
Using SyncVu
WFM5200 Waveform Monitor User Manual
The SyncVu™ feature works with the simultaneous input monitoring (SIM) mode
and allows you to configure the settings for two inputs at the same time. (See
page 29, Simultaneous Input Monitoring.)
To set the instrument to SyncVu™ mode after you are in SIM mode, do the
following:
1. Press the MAIN button.
2. Select SyncVu.
3. Select Enable.
This instrument can display four tiles. When you are viewing two inputs
simultaneously in SIM mode, the tiles on the left side of the display show the first
input. The tiles on the right side of the display show the second input. The display
type in tile 1 for the first input is the same display type shown for the second input
in tile 2: Top left to top right and bottom left to bottom right. SyncVu™ allows
you to change the settings for the two related tiles at the same time.
For example, if you have a waveform display in tile 1 of input 1A, then tile 2 is
the waveform display for the second input. When you adjust the settings for the
waveform displayed in tile 1, the settings for the waveform displayed in tile 2 are
adjusted simultaneously. Similarly, adjusting settings for tile 2 are applied to tile 1.
Display Information
35
