Functions
To Save Presets
To Recall Presets
90
Display settings
Readout setting
Graticule settings
The instrument can store up to 32 separate instrument presets. The presets are
divided into four groups, A through D, with each group containing 8 preset storage
locations. The default preset names are A1 – A8, B1 – B8, C1 – C8, and D1 – D8.
Quick access to presets 1 – 8.
1. Set up the instrument exactly as you want to have it configured. This includes
setting the contents of each tile and the audio and video settings.
2. Press and hold one of the preset buttons (1 through 8) to which you want
to save the setup.
NOTE. Pressing and holding a preset button accesses the Group A preset locations
by default. You can use the Bezel Group Select menu in the Preset menu to change
which of the four preset groups are associated with the front panel preset buttons.
3. In the dialog box that appears, press the right arrow key to highlight the
Continue box.
4. Press the SEL button. A message displays that your preset is saved.
Access to all presets.
1. Set up the instrument exactly as you want to have it configured. This includes
setting the contents of each tile and the audio and video settings.
2. Press the PRESET button to display the Preset Menu.
3. Use the arrow buttons to navigate to a preset location to save the instrument
settings. For example select Save Preset > Select Group B > Save B1.
4. Press the SEL button. A message will display that your preset is saved.
Recalling presets is easy: press the PRESET button to display the Preset Menu.
Use the arrow buttons to navigate to the preset that corresponds to the preset
you want and press the SEL button.
To recall factory presets, press the PRESET button to display the Preset Menu.
Use the arrow buttons to navigate to Recall Preset > Recall Factory Preset
and then press the SEL button.
