Closed Captioning (CC), Teletext, AFD, and Safe Area Compliance
Usage Notes

Monitoring for Safe Area Compliance

To Configure Safe Area
Graticules
To Display Safe Area
Graticules
134
PICT displays in individual tiles allow their Services and Pages to be selected
independently.
CC text is not captured with the Picture image when using Freeze.
CC/Teletext setups are also stored when saved with Presets and restored at
power on.
The CC alarms are available from the Configuration menu in the Alarms
submenu under Closed Captions/Metadata.
Teletext can be viewed as captions or as a whole page.
To display graticules for monitoring for incorrect placements of nonessential
elements relative to essential ones, set global settings in the Configuration menu
and turn on up to four Safe Area graticules, each with independent settings, in
the Picture menu.
Before using Safe Area Graticules, configure them from the Configuration menu
by performing the following steps:
1. Select Graticules and then select Safe Area Graticule Standard from the
CONFIG menu.
2. Choose from the SMPTE, ITU, or ARIB TR-B.4 standards. The selection
you choose will be the graticule used when AUTO is chosen for any of the
four Safe Area Graticules, accessed in the Picture menu.
3. To set the Height, Width, and Offsets of the title and action areas for Custom
Safe Graticules 1 and 2, first select the title or action to change.
4. Set the percentage level for each of the parameters. Parameters are set as a
percentage of screen height or width, and you can watch the graticules update
on the screen as you change them.
NOTE.
The custom parameters you set are used when Custom_1 or Custom_2 is
chosen for any of the four Safe Area Graticules accessed in the Picture menu.
1. Select a tile.
2. Press and hold the PICT button to display the Picture menu.
3. Select Safe Area Action 1.
