Elements of the Gamut
Display
GAMUT Pop-Up Menu
WFM5200 Waveform Monitor User Manual
High threshold: Shows the currently specified high threshold (Diamond
High or Arrowhead Max).
Low threshold: Shows the currently specified low threshold (Diamond Low).
Gamut display type: Shows the selected Gamut display type - Diamond,
Split Diamond, Quad Diamond, Spearhead, or Arrowhead.
Threshold indicators: Indicates the threshold settings using blue dashed
lines.
Luma minimum: Shows the currently specified minimum luma threshold
(in the Arrowhead display).
Luma maximum: Shows the currently specified maximum luma threshold
(in the Arrowhead display).
The GAMUT pop-up menu allows you to select the type of gamut display shown
in the active tile and to turn on Multi-Input display mode. To change the display
type, use the pop-up menu to select from the following displays:
Diamond shows Gamut violations of the SDI input if translated to RGB
color space.
Quad Diamond shows a disparity histogram of the left and right channels of
a 3D signal.
Split Diamond offsets the two halves of the Diamond to allow you to better
see negative RGB Gamut errors.
Arrowhead shows Gamut violations of the SDI input if translated to the
Composite domain.
Spearhead shows lightness, color value, and saturation of the RGB color
space of all video signals, including dual link signals.
To turn on the Multi-Input display mode, select Multi-Input Display and press
SEL. Next, press and hold the Display Select button to view the display full-tile
and activate the Multi-Input view.
NOTE.
The Multi-Input menu option is only available in the GAMUT pop-up
menu when the feature is enabled from the MAIN button or CONFIG button menu.
(See page 26, Multi-Input Display Mode.)
NOTE.
The 3D display menu options are only available in the GAMUT pop-up
menu when the feature is enabled from the MAIN button menu. (See page 30,
3D Input Monitoring.)
Display Information
45
