Display Information

3D Input Monitoring

How to Access the 3D
Menus
30
Your instrument can monitor stereoscopic 3D content in production and post
production applications with Option S3D installed. A 3D image is comprised of
a Left Eye and Right Eye view as two separate HD-SDI signals or combined
within a 3G Level B format.
A 3D signal can be carried within a single SDI signal (Side by Side) as a left and
right image in either two SDI signals or a 3G level B 2xHD (Dual Stream) signal.
You can select the input type in the MAIN button menu.
There are a variety of 3D displays to help you determine the difference between
the left and right images, and therefore the depth of an object in an image.
NOTE.
Side by Side monitoring is only available in the Picture display.
Before you can view and use the 3D menu items in the WFM button menu and
other measurement display menus, do the following:
1. Press the MAIN button.
2. Select 3D Input Type.
3. Select the input type and press the SEL button.
