Audio Monitoring
To Check Audio Level and Phase
To Check Audio Level
124
3. Use the Arrow Keys and SEL button to make selections in the steps that
follow.
4. Select Audio Input and then select one of the audio input options shown.
NOTE.
The available selections depend on the installed audio option. Selecting
Follows Video selects the audio to video mapping set in the configuration menu.
(See page 123, Configuring Audio Inputs.)
Level meters are vertical bar graphs on which the height of the bar indicates the
amplitude of the audio program in the corresponding input channel. Use the
Audio pop-up menu to change the input and turn on and off the Phase display.
Other meter characteristics such as ballistics, scale units, and program and test
levels are configured through the Configuration menu.
If your instrument is equipped with optional audio features, it can display phase
of one input pair as a Lissajous pattern, and display relative phase on all four
pairs of inputs with correlation meters.
1. Open the audio display in one tile and select an input. (See page 123, To Set
Up an Audio Input.)
2. Check the level meter bars for current audio levels, which are displayed
according to the selected meter ballistics. Each bar displays three colors.
(See Figure 56.)
Green – Indicates audio levels below the test level.
Yellow – Indicates audio levels between the test and peak program level.
Red – Indicates audio levels above the peak program level.
