5 To remove the arrow, press the arrow key and then select Hide.
To place a pictograph on an image
The pictograph set available depends on transducer and exam type.
1 Press the PICTO key.
2 Select x/x to display the desired pictograph, and then press the SELECT key.
The first number shows which pictograph in the set is selected. The second number is the number of
pictographs available.
3 Using the touchpad, position the pictograph marker.
4 (Optional) If the image is frozen, use the touchpad or arrow keys to pan the image up, down, left, and
right. You cannot pan in Dual.
5 To rotate the pictograph marker, press the SELECT key and then use the touchpad.
6 Choose a screen location for the pictograph:
U/L (Up/Left
D/L (Down/Left)
D/R (Down/Right)
U/R (Up/Right)
In a duplex layout, the pictograph is restricted to upper left. In Dual, all four positions are available.
7 To remove the pictograph, select Hide.

Patient information form

The patient information form lets you enter patient identification, exam, and clinical information for the
patient exam. This information automatically appears in the patient report.
Note
To create a new patient information form
Creating a new patient information form removes any unsaved patient information, including calculations and
report page.
1 Press the PATIENT key.
The current patient information form appears.
Imaging
When you create a new patient information form, all images and other data you
save during the exam are linked to that patient. See
worksheets" on page 5-38.
"Patient reports and
4-25
