Table 2-1: Keyboard map (continued)
18
SETTINGS
PATIENT
EXAM
REVIEW
REPORT
19 Power switch

Screen layout

1
2
3
4
5
6
7
8
Figure 2-4 Sample screen
Table 2-2: Screen map
1 Mode Data Area
2-14
Accesses the setup pages.
Accesses patient information.
Opens exam menu.
Accesses the patient list, saved images, and archiving functions.
Accesses the patient report and EMED worksheets.
Turns system on and off.
Current imaging mode information (for example, Gen, Res, THI,
and PW).
9
10
11
