Network Status setup

The Network Status setup page displays information on system IP address, Location, Ethernet MAC
address, and the wireless connection if any.

OB Calculations setup

WARNING
On the OB Calculations setup page, you can select authors for OB gestational calculation tables. Refer to
"OB calculations" on page 5-30.
To specify gestational age and growth analysis
1 On the OB Calculations setup page, select the desired OB authors (or select None) in the measurement
lists under Gestational Age and Growth Analysis.
Selecting an author places the associated measurement on the calculations menu.
2 (Optional) Select More to display the list of user-defined custom measurements and to associate a
custom table for the custom measurement.
Note
To export OB calculation tables
1 Insert a USB storage device.
2 On the OB Calculations setup page, select Export. A list of USB devices appears.
3 Select the USB storage device, and select Export. All user-defined tables and measurements are copied
to the USB storage device.
To import OB calculation tables
Tables that you import are added to those already on the system.
1 Insert the USB storage device that contains the tables.
2 On the OB Calculations setup page, select Import on-screen.
3 Select the USB storage device, and then select Import.
4 Select OK in the dialog box that appears. The system restarts.
System Setup
To prevent injury or misdiagnosis, do not use this system for fetal growth
screening if the advanced OB calculations and reports package is not available.
This option is available only when a user-defined custom table has been created
for the custom measurement.
3-11
