FujiFilm SonoSite Edge II User Manual page 23

Table 2-1: Keyboard map (continued)
5 AUTO
6
ZOOM
7 DEPTH UP,
DEPTH DOWN
8 SET
CALIPER
9 CALC
10 Touchpad
11 FREEZE
12 SAVE
13 SAVE CALC
CLIP
14
Imaging Modes
M MODE
DOPPLER
COLOR
2D
15 A & B shortcut keys
16 UPDATE
17 SELECT
Getting Started
Adjusts gain automatically.
Magnifies the image 100%.
Decreases and increases imaging depth.
Sets a trace measurement.
Displays calipers on-screen for measuring.
Turns the calculations menu on and off.
Selects, adjusts, and moves items on-screen.
Stops live imaging and displays a frozen image.
Saves an image to internal storage. If configured, also saves calculations
to the report. Refer to "Presets setup"
Saves calculations and their measurements to the patient report.
Saves a clip to internal storage.
Turns M Mode on, toggles between M-line and M Mode trace.
Turns Doppler on, toggles between D-line and Doppler trace.
Turns CPD/Color on and off.
Turns 2D on.
Keys that you can program to perform common tasks.
Toggles between dual and duplex screens and imaging modes in
M Mode and Doppler (for example, between D-line and Doppler spectral
trace).
Used with the touchpad to select items on-screen. Also switches
between Color and Doppler controls, calipers for measurement,
pictograph-marker position and angle, frozen images in duplex and dual
screens, and arrow position and orientation.
on page 3-14.
2-13
