FujiFilm SonoSite Edge II User Manual page 107

6 Position the caliper, and press the SELECT key. Repeat for each measurement name in the calculation
group.
Note
7 Save the calculation as described in
To measure Heart Rate in Doppler
For more information about how heart rate (HR) is used in calculations, see
page 5-15
Saving the heart rate to the patient report overwrites any heart rate entered on the patient information form.
1 On a frozen Doppler spectral trace, press the CALCS key.
2 From the calculations menu, select HR.
A vertical caliper appears.
3 Using the touchpad, position the first vertical caliper at the peak of the heartbeat.
4 Press the SELECT key.
A second vertical caliper appears. The active caliper is highlighted.
5 Using the touchpad, position the second vertical caliper at the peak of the next heartbeat.
6 Save the calculation as described in
To measure Ao, LA, AAo, or LVOT D
1 On a frozen 2D image or M Mode trace, press the CALCS key.
2 From the calculations menu, select the measurement name.
3 Position the calipers.
4 Save the calculation as described in
To calculate MV or AV area
1 On a frozen 2D image, press the CALCS key.
2 In the Area menu, select MV or AV.
3 Position the caliper where you want to begin the trace, and press the SELECT key.
4 Using the touchpad, trace the desired area.
To make a correction, select Undo on-screen or press the backspace key.
5 Complete the trace, and press the SET key.
6 Save the calculation as described in
To calculate LV mass
1 On a frozen 2D image, press the CALCS key.
2 In the calculations menu, locate LV mass.
Measurements and Calculations
Each time you press the SELECT key, another caliper appears, and the
calculations menu highlights the next measurement name.
"To save a calculation"
"To save a calculation"
"To save a calculation"
"To save a calculation"
on page 5-8.
"Cardiac calculations"
on page 5-8.
on page 5-8.
on page 5-8.
on
5-23
