2-plane Simpson's rule (method of disks)
LA Vol = /4(h) (D1)(D2)
Simpson's algorithm divides the LA into a series of stacked oval disks where h is the height of the stacked
disks and D1 and D2 are the orthogonal minor and major axes
1-plane Simpson's rule (method of disks)
LA Vol =/4(h) (D1)
Same as the 2-plane method of disks except there is an assumption that the stacked disks are circular.
The equation for the LA Vol Index is: LA Vol Index = LA Vol/BSA
Left Atrial Volume Index
Lang, R., M. Bierig, R. Devereux, et al. "Recommendations for chamber quantification: a report from the
American Society of Echocardiography's guidelines and standards committee and the chamber
quantification writing group, Developed in conjunction with the European Association of
Echocardiography, a branch of the European Society of Cardiology." Journal of the American Society of
Echocardiograph. 2005, 18: p.1440-1463.
Left Ventricular End Volumes (Teichholz) in ml
Teichholz, L.E., T. Kreulen, M.V. Herman, et al. "Problems in echocardiographic volume determinations:
echocardiographic-angiographic correlations in the presence or absence of asynergy." American Journal
of Cardiology. (1976), 37: p.7.
LVESV = (7.0 * LVDS
where:
LVESV = Left Ventricular End Systolic Volume
LVDS = Left Ventricular Dimension at Systole
LVEDV = (7.0 * LVDD
where:
LVEDV = Left Ventricular End Diastolic Volume
LVDD = Left Ventricular Dimension at Diastole
Left Ventricular Mass in gm for 2D
Oh, J.K., J.B. Seward, A.J. Tajik. The Echo Manual. 3rd ed., Philadelphia: Lippincott, Williams, and Wilkins,
(2007), p.113-114.
LV Mass = 1.05 * {[(5/6) * A1 * (a + d + t)] - [(5/6) * A2 * (a + d)]}
where:
1.05 = Specific gravity of the myocardium
A1 = Short axis area, diastole (Epi)
A2 = Short axis area, diastole (Endo)
a = Long or semi major axis
d = Truncated semi major axis from the widest short axis diameter to mitral annulus plane.
t = Myocardial thickness
6-8
2
3
)/(2.4 + LVDS)
3
)/(2.4 + LVDD)
