13.8
C oordinate Origin
7 0 B
The positioning unit sets the coordinate managed to 0 by the home return process.
Coordinate origin is a function to set the coordinate after the home return process to an arbitrary value.
Procedure of coordinate origin process
1. Write the coordinate to be the origin in the coordinate origin value area for the axis of which coordinate
will be changed after the home return.
2. Execute the home return for the target axis. After the home return, the coordinated specified in the
above 1 becomes the origin.
Offset
Name
address
04AH
Coordinate origin
04BH
Reference: <17.6.2 Parameter Setting Area>
Note: The coordinate origin value should be specified in the specified unit. The value to be
changed by the coordinate origin value is the feedback value after unit conversion.
Description
Stores the value of coordinate origin after the home return.
13-11
