7.5.2
R eading from Files
9 9 B
Read the parameter settings or data settings from files.
1. Select [File] → [Open] in the menu bar, or click [Open] icon in the toolbar. The following dialog
is shown.
2. Select the drive where the file is saved in the [Location of File] box.
3. Select the file name in the box listing the folders and files under the [Location of File] box.
If the file you want to read is not indicated, double-click the folder name where the file is saved.
Double-click the sub-folder names until the sub-folder where the file is saved is open.
4. Click the file name.
The following contents are recorded in the positioning setting file (* npm) that can be used in this
software.
・Axis information
・Parameter settings
・Data settings
・Data comments
5. Click [Open].
Key Point:
Click the file name indicated at the bottom of the [File] menu to open the file that was previously active
7-14
