Port Forwarding Rule
Enabled
Delete
Name
Ingress IP Address: Port
Range
Protocol
IP Address: Target Port Target for the port forwarding rule.

To Configure Gateway Port Forwarding Settings

Using Web Manager
To modify gateway port forwarding information, click Gateway on the menu and select
Configuration > Port Forwarding.
Using the CLI
To enter the gateway command level: enable -> config -> gateway -> port
forwarding rule <number>
Using XML
Include in your file: <configgroup name="gateway"> <configitem name="port
forwarding" instance="<number>">

Static Routes

Allows the user to add routes to the device routing table.
Static Route Settings
Enabled
Delete
Name
Route
Applied
PremierWave® Intelligent Gateway User Guide

Table 6-12 Port Forwarding Rules List

Description
Enables the port forwarding rule.
Deletes the port forwarding rule.
User friendly name for the rule. Click on the [Edit] icon to make changes.
Port or Port range for the rule.
Protocols for the rule: TCP, UDP, or Both.

Table 6-13 Adding a New Port Forwarding Rule

Table 6-14 Static Route Setting Routes

Description
Enables the static route.
Deletes the static route.
User friendly name for the route. Click on the [Edit] icon to make changes.
Network or Host for the route.
If the route was successfully applied. Routing table updates require a
reboot and route needs to be valid as per other device configurable.
6: Network Settings
49
