Figure 3-7 PremierWave XC HSPA+ Pinout Configuration for Full Duplex RS-422/485 (4-wire)

Figure 3-8 PremierWave XC HSPA+ Pinout Configuration for Half Duplex RS-422/485 (2-wire)

Ethernet LEDs
The Ethernet port (see
described in the
Color/Status
Green
Amber
The Ethernet port can connect to an Ethernet (10 Mbps) or Fast Ethernet (100 Mbps) network.
Reset Button
You can reset the PremierWave XC HSPA+ intelligent gateway to factory defaults, including
clearing the network settings. The IP address, gateway, and netmask are set to 00s. To reset the
unit to factory defaults, perform the following steps.
1. Place the end of a paper clip or similar object into the reset opening (see
and hold down micro switch during a power cycle for 10-15 seconds.
PremierWave® XC HSPA+ Intelligent Gateway User Guide
Figure 3-11) has two LEDs that indicate the status of the connection as
Table 3-9 and Table 3-10

Table 3-9 Left Ethernet LED

Solid Light
100 Mbps Link
10 Mbps Link

Table 3-10 Right Ethernet LED

Color/Status
Green
OFF
3: Installation of the PremierWave XC HSPA+ Device
below:
Blinking Pattern
100 Mbps Activity
10 Mbps Activity
Solid Light
Full Duplex
Half Duplex
Figure 3-5) and press
25
