Action Settings
FTP Put
HTTP Post
Relay
GPRS Roaming
SMS
SNMP Trap

To Configure Action Settings

Using Web Manager
To view Action status information, click Action on the menu and select Status.

To modify Action information, click Action on the menu and select a specific action from the

drop-down menu.
Using the CLI
To enter the eth0 link state change command level: enable -> config -> action ->

eth0 link state change
PremierWave® XC HSPA+ Intelligent Gateway User Guide
Description
Use FTP Put to put a file on configured FTP server.
Filename will be used to upload to remote FTP server. The IP Address or hostname
is the FTP server to connect. Port number is port on which FTP server is listening on.
Use Protocol to connect to FTP server. FTPS is a SSL encrypted communication
channel and SSL Trusted Authorities must be setup with FTP server SSL certificate.
Username is used to logon to FTP server. If FTP server does not require
authentication, use anonymous. Password is used to logon to FTP server. If FTP
server does not require authentication, a common practice is to use user's email
address. If the alarm stays on or off longer than the Reminder Interval, another FTP
Put is performed. In Sequential mode, connections will be attempted starting with
number 1 until a connection is successful. In Simultaneous mode, all possible
connections will be made.
Use HTTP Post post to configured HTTP server.
The URL appears behind the HTTP server IP address or hostname. E.g. http://
some_http_server/some_url The IP Address or hostname is the HTTP server to
connect to. Port number is the port which HTTP server is listening on. Use Protocol
to connect to HTTP server. HTTPS is a SSL encrypted communication channel and
SSL Trusted Authorities must be setup withHTTP server SSL certificate. Username
used to logon to HTTP server if authentication is required. Password used to logon to
HTTP server if authentication is required. If the alarm stays on or off longer than the
Reminder Interval, another HTTP Post is performed. In Sequential mode,
connections will be attempted starting with number 1 until a connection is successful.
In Simultaneous mode, all possible connections will be made.
Select a Relay to switch on when this alarm is activated. Select "None" so this alarm
state will have no effect on any Relay.
Select to enable or disable GPRS roaming when this alarm is on. Select No Change
so this alarm State will have no effect on GPRS roaming.
Use SMS to send SMS to a configured Recipient.
The contents of Alarm Message will be placed into the SMS body when an alarm
SMS is sent. If the alarm stays on longer than the Reminder Interval, another alarm
SMS is sent. The contents of Normal Message will be placed into the SMS body
when a normal SMS is sent. If the alarm stays off longer than the Reminder Interval,
another normal SMS is sent.
Use SNMP Trap to send SNMP trap to configured trap destinations.
Check to enable or disable the State. The contents of Alarm Message are included
when an alarm SNMP trap is sent. If the alarm stays on longer than the Reminder
Interval, another alarm SNMP Trap is sent. The contents of Normal Message are
included when a normal SNMP trap is sent. If the alarm stays off longer than the
Reminder Interval, another normal SNMP Trap is sent.
Alarms and Reports (on page 62) lists the options.
