Gateway Settings
Secondary DNS
WAN MAC Address Filters
Accept or drop traffic from specified MAC addresses using the settings below.
Adding or Deleting New MAC
Address Filter Settings
Delete
MAC Address
Action
Add
To Configure Gateway WAN Settings
Using Web Manager
To modify gateway WAN information, click Gateway on the menu and select Configuration >
WAN.
Using the CLI
To enter the gateway command level: enable -> config -> gateway
Using XML
Include in your file: <configgroup name="gateway"> <configitem name="wan">
Port Forwarding
Port forwarding allows remote computers (for example, computers on the Internet) to connect to a
specific computer or service within a private local-area network (LAN). Port Forwarding rules
apply to inbound traffic and will not work under these conditions:
The IP of the cellular device is not directly reachable from outside of the cellular providers
network. The port forwarding rules will not work if the device does not receive any traffic.
Hosts within the cellular providers network cannot reach the device.
The port is blocked by the cellular provider.
If traffic to certain ports is blocked before it reaches the PremierWave device, the port
forwarding rules will still not work even with a public and accessible IP.
PremierWave® Intelligent Gateway User Guide
Description
Enter the IP address of the secondary Domain Name Server.
Note:
This setting will be used when either Static IP or Auto IP is active, or
if DHCP/BOOTP is active and no DNS server was acquired from the
server.
Table 6-11 Adding a New MAC Address Filters
Description
Click the checkbox to the left of any existing mac address filter to be
deleted and click the Submit button.
Enter a new mac address to add a new filter.
Select to ACCEPT or DROP above indicated MAC Address field.
Click Add after adding new MAC address filter information.
6: Network Settings
48
