To Configure An Existing Ssl Credential - Lantronix PREMIERWAVE XC HSPA+ User Manual

Certificate Generation
Settings (continued)
Organization Unit
Common Name
Expires
Type
Key Length
Submit (key)

To Configure an Existing SSL Credential

Follow these steps after a new credential has been established via
page 105.
Using Web Manager
To configure an existing SSL Credential, click SSL in the menu, select Credentials, and click

on the name of an existing SSL credential.
Using the CLI
To enter the SSL command level: enable -> ssl

To enter the Credential command level: enable -> ssl -> credentials

Using XML
Include in your file:

<configgroup name="ssl">
and <configitem name="credentials" instance="name">
and <value name="RSA certificate"/> or <value name="DSA certificate"/>
PremierWave® XC HSPA+ Intelligent Gateway User Guide
Description
Enter the organizational unit to be associated with the new self-signed
certificate.
Enter the common name to be associated with the new self signed
certificate, preferably matching the host name or the ip address of the
device, whichever will be the intended access approach. This is a required
field.
Enter the expiration date, in mm/dd/yyyy format, for the new self-signed
certificate.
Example: An expiration date of May 9, 2018 is entered as 05/09/2018.
Select the type of key:
RSA = Public-Key Cryptography algorithm based on large prime

numbers, invented by Rivest Shamir and Adleman. Used for encryption
and signing.
DSA = Digital Signature Algorithm also based on large prime numbers,

but can only be used for signing. Developed by the US government to
avoid the patents on RSA.
Select the bit size of the new self-signed certificate. Choices are:
512 bit

768 bit

1024 bit

2048 bit

4096 bit

The larger the bit size, the longer it takes to generate the key.
Click the Submit button after setting the information for new self-signed
certificate.
15: Security Settings
Create a New Credential on
107
