To Configure Gateway WAN Settings

Using Web Manager
To modify gateway WAN information, click Gateway on the menu and select Configuration >

WAN.
Using the CLI
To enter the gateway command level: enable -> config -> gateway

Using XML
Include in your file: <configgroup name="gateway"> <configitem name="wan">


Port Forwarding

Port forwarding allows remote computers (for example, computers on the Internet) to connect to a
specific computer or service within a private local-area network (LAN). This functionality will not
work if the cellular provider uses NAT.
Port Forwarding Rule
Enabled
Delete
Name
Port or Port Range
Protocol
IP Address
Adding New Port
Forwarding Rule
Settings
Name
Start Port
End Port
Protocol
IP Address

To Configure Gateway Port Forwarding Settings

Using Web Manager
To modify gateway port forwarding information, click Gateway on the menu and select

Configuration > Port Forwarding.
PremierWave XC HSPA+ User Guide
PRELIMINARY DRAFT

Table 6-4 Port Forwarding Rules List

Description
Enables the port forwarding rule.
Deletes the port forwarding rule.
User friendly name for the rule. Click on the [Edit] icon to make changes.
Port or Port range for the rule.
Protocols for the rule: TCP, UDP, or Both.
Target for the port forwarding rule.

Table 6-5 Adding a New Port Forwarding Rule

Description
User Friendly name for the rule {optional)
Starting port number
End port number (optional). If start port and end port are same it assumes a
single port. If start port and end port are not the same – it is a port range.
Protocols for the rule. TCP, UDP, or Both
Target for the port forwarding rule.
