Web Manager Components

The layout of a typical Web Manager page is below.
Header
Menu Bar
Footer
Web Manager pages have these sections:
The menu bar always appears at the left side of the page regardless of the page shown. The menu
bar lists the names of the pages available in the Web Manager. To bring up a page, click it in the
menu bar.
PremierWave® XC HSPA+ Intelligent Gateway User Guide

Figure 5-2 Components of the Web Manager Page

Items to
configure
Configuration and/or Status Area
5: Configuration Using Web Manager
Links to
subpages
Information
and Help Area
Logout
button
34
