Troubleshooting Capabilities

The PremierWave XC HSPA+ device server offers a comprehensive diagnostic toolset that lets
you troubleshoot problems quickly and easily. Available from the CLI or Web Manager, the
diagnostic tools let you:
View critical hardware, memory, buffer pool, IP socket information and routing table

Perform ping and traceroute operations

Conduct forward or reverse DNS lookup operations

View all processes currently running on the PremierWave XC HSPA+ intelligent gateway

including CPU utilization
View system log messages


Configuration Methods

After installation, the PremierWave XC HSPA+ unit requires configuration. For the unit to operate
correctly on a network, it must have a unique IP address on the network. There are four basic
methods for logging into the PremierWave XC HSPA+ intelligent gateway and assigning IP
addresses and other configurable settings:
Web Manager: View and configure all settings easily through a web browser using the

Lantronix Web Manager. (See
DeviceInstaller: Configure the IP address and related settings and view current settings on

the PremierWave XC HSPA+ intelligent gateway using a Graphical User Interface (GUI) on a
PC attached to a network. You will need the latest version of the Lantronix® DeviceInstaller™
utility. (See
30.)
Command Mode: There are a few methods for accessing Command Mode (CLI): making a

Telnet connection, or connecting a PC or other host running a terminal emulation program to
the unit's serial port. (See the PremierWave XC HSPA+ Intelligent Gateway Command
Reference for instructions and available commands.)
XML: The PremierWave XC HSPA+ intelligent gateway supports XML-based configuration

and setup records that make device configuration transparent to users and administrators.
XML is easily editable with a standard text or XML editor. (See the PremierWave XC HSPA+
Intelligent Gateway Command Reference for instructions and commands).

Addresses and Port Numbers

Hardware Address

The hardware address is also referred to as the Ethernet address, physical address, or MAC
address. The first three bytes of the Ethernet address are fixed and identify the unit as a Lantronix
product. The fourth, fifth, and sixth bytes are unique numbers assigned to each unit. Sample
hardware address:
 00-80-A3-14-1B-18
 00:80:A3:14:1B:18
PremierWave® XC HSPA+ Intelligent Gateway User Guide
Configuration Using Web Manager on page
Accessing the PremierWave XC HSPA+ Device Using DeviceInstaller on page
2: Introduction
32.)
19
