To Configure Network 2 Interface Settings

Using Web Manager
To modify network 2 wwan0 interface information, click Network on the menu and select

Network 2 > Interface > Configuration.
Using the CLI
To enter the cellular command level: enable -> config -> if 2

Using XML
Include in your file: configgroup name = "cellular interface" instance =

"wwan0">

Network 2 (Cellular "wwan0") Link Settings

This page shows configuration of an wwan0 link on the device.
Network 2 Link
Settings
APN
Username
Password
Dialup String
Roaming

To Configure Network 2 Link Settings

Using Web Manager
To modify network 2 wwan0 interface information, click Network on the menu and select

Network 2 > Link > Configuration.
Using the CLI
To enter the link command level: enable -> if 2 -> link

Using XML
Include in your file: <configgroup name = "wwan0 link" instance = "wlan0">

PremierWave® Intelligent Gateway User Guide

Table 6-7 Network 2 (wlan0) Link Settings

Description
Enter the configurable network identifier used by a mobile device when
connecting to a GSM carrier.
Enter the Username for dial up to cellular carrier, if required.
Enter the Password for dial up to cellular carrier, if required.
Enter the modem string used for making connection to carrier.
Enable or disable the network roaming.
6: Network Settings
45
