Xml: Import Configuration; Table 17-6 Import Configuration From Filesystem Settings - Lantronix PREMIERWAVE XC HSPA+ User Manual

Using the CLI
To enter the XML command level:

Using XML
Not applicable.


XML: Import Configuration

Here you can import a system configuration from an XML file.
The XML data can be imported from a file on the file system or pasted into a CLI session. The
groups to import can be specified at the command line, the default is all groups.
Configuration from External File
This import option requires entering the path and file name of the external XCR file you want to import.
Configuration from Filesystem
This import option picks up settings from a file and your import selections of groups, lines, and
instances. The list of files can be viewed from the filesystem level of the CLI.
Line(s) from single line Settings on the Filesystem
This import option copies line settings from an the input file containing only one Line instance to all
of the selected Lines.
Import Configuration from
Filesystem Settings
Filename
Lines to Import
Whole Groups to Import
Export (button)
PremierWave® XC HSPA+ Intelligent Gateway User Guide

Table 17-6 Import Configuration from Filesystem Settings

Description
Enter the name of the file on the PremierWave unit (local to its filesystem)
that contains XCR data.
Select filter instances to be imported in the line, serial, tunnel and terminal
groups. This affects both Whole Groups to Import and Text List selections.
Click Clear All to clear all checkmarks, or Select All to check all
checkmarks.
Select the configuration groups to import from the XML configuration
record. This option imports all instances of each selected group. Click
Clear All to clear all checkmarks, or Select All but Networking to check
all checkmarks except Networking.
Click Export after selecting the XML: Import Configuration settings.
17: Management Interface Settings
enable -> xml
124
